Modore 140 MKII

The Modore 140 is a direct vent fireplace with a 55” wide viewing area and a sleek design which allows the installation to have a thoroughly modern and completely trimless finish.

Element4 fireplaces feature unique Fire Media options, which sit directly in the flames. Choose between log set, fire glass, white Carrara pebbles or grey stones.

The Modore 140 comes standard with all MKII features such as designer trim, improved tube-style burners, and the E-Save Control System which can save up to 40% on fuel consumption.
More MKII Details

The Modore 140 is produced by Element4 B.V., the award winning fireplace manufacturer from the Netherlands, and is imported and distributed by European Home for installations in North America.
Find a local dealer today.

Specifications

Gas Type
Natural Gas or Propane
Heat Input (Natural Gas)
13,650 - 38,200 BTU/hr
Heat Input (LPG)
11,950 - 34,100 BTU/hr
Viewable Opening
54-5/8" W x 16-1/2" H
Framing
Please refer to the Installation Manual for more information
Venting
Requires 5" x 8" direct vent
Flame Adjustment
Yes
Interior
Anthracite Flat Black or Optional Reflective Black
Options
Wall Switch
Remote Control
Yes
Electronic Ignition
Yes
Certification
ANSI Z21.11.50a-2008, CSA 2.22a-2008, CSA P.4 - Vented Gas Fireplaces
Efficiency
80.6%

Select a document to view:

Manuals:

Product File Revision Letter
Installation Manual for MKII PDF B
4 Button Remote Operation Guide PDF A
8 Button Remote Operation Guide PDF A
Optional Internal Wall-Mount Power Vent Manual PDF A
Optional External Roof-Mount Power Vent Manual PDF A
ProControl App Manual PDF A

Design Files:

Brochures:

Optional Designer Interiors

Black Reflective

Reflective Pannels

Concrete Style

Tri140MockWconcrete

Convection Air Opening Trim

Convection air openings are fitted on the sides of the fireplace chase to avoid very high temperatures within the chase. Built-in dimension (H x W).

You’re free to use your own trims. The opening for Modore 140 must be at least 70 square inches of unrestricted opening.

Convention Air Opening Trim

Access Door

Access door for Element4 frameless gas fires for mounting the gas control block. Outer frame dimensions: 8-7/16” W x 11-1/4” H.

Access Door

Safety Screen

Safety Screen

 Optional Wall Switch

Wall Switch

  • Grey stones fire media burning
    Grey Stones
  • Fall Birch fire media burning
    Fallen Birch
  • Carrara pebbles fire media
    Carrara Pebbles
  • Tundra fire media
    Tundra
  • Log set fire media
    Log Set
  • Forest Path fire media
    Forest Path
